Features
Working pressure:
-
1 to 5 bar
Flow:
-
6 to 8 l/mn at 3 bar with integrated flow regulator
-
Anti-water-hammering design
-
Fixed shower head with orientable shower jet and anti-limescale spikes
Operation:
-
Hygienic electronic detection cell suitable for elderly and disabled people
-
Detection range of the hand in front of the cell: 10 cm
Flow time:
-
30 seconds - Adjustable through PRESTOCOM
-
Start / Stop function. Stop not possible during the first 10 seconds - Adjustable through PRESTOCOM
Hydraulic supply:
-
G 1/2" (15x21) top water inlet with straight stop valve
-
For cold water
Power supply:
-
6 volt CRP2 lithium battery in integrated box
Material and colour finish:
-
Injected molded metal body and cover
-
Extruded profile in Aluminium-Magnesium-Silicium alloy 6060
Security:
-
Automatic shut-off of the solenoid valve in case of dead battery
Shipped with:
-
VBA screws and nylon plugs
-
MF G 1/2" stop valve and filters
Standards & approvals:
-
Molded chrome-plated body in accordance with EN 12540
-
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
-
Brass UBA List compliant
Specification
Single electronic / sensor shower tap with battery and straight stop valve
