Features
Working pressure:
-
1 to 5 bar
Flow:
-
1.9 l/min with integrated spray flow limiter
-
High quality anti-limescale sprayer
-
Anti-water-hammering design
Hydraulic supply:
-
On Male G 1/2" (15x21) connection - Cold or premixed water
Power supply:
-
Low voltage power supply (12-24V AC/DC) in IP65 Water Proof case (transformer unit not provided)
Material and colour finish:
-
Injected metal and brass. Chrome plated.
Thermal resistance:
-
Resistant to a temperature of 75°C for 30 minutes thermal shocks
Security:
-
Anti-overflow security time: 30 seconds (anti-blocking system preventing the water to flow continuously)
-
Automatic shutdown of solenoid valve in case of power failure or sensor error
-
Duty flush 45s each 24h after last use
Delivered with:
-
1 Mounting assembly kit (Clamping & nut)
-
1 Filter gasket
-
1 solenoid valve
-
1 power supply (transformer unit not provided)
-
1 installation guide
Standards & approvals:
-
Brass in accordance with EN1982, EN12164 & EN1165
-
Brass UBA list compliant
-
REACH and RoHS compliant
-
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
-
WRAS certified
Specification
PRESTO NEO Sensor wall-mounted - Power Supply
