Smart Water Control Systems

Function:

• This bent tube for PRESTO 1000 and PRESTO 1000 XL flush valves allows water to drain into a toilet bowl

Material and finish color:

• PVC

Dimensions:

• Ø 28 mm

• Length: 500 mm (D32mm)

• Width: 300 mm (D28mm)

Delivered with:

• 1 Tube D32mm Lg 500mm

• 1 Tube D28mm Lg 300mm

• 1 Reduction sleeve D28/D32mm

• 1 Joining nipple D inside 28-32 / D outside 55mm

• 1 Installation instructions

Use recommendations:

• IMPORTANT: the minimum height of a flush pipe is 500 mm, do not reduce it. Never use an American joint fitting on the flush valve or stopcock inlet (the circuit is under pressure).

TUBE PVC FOR PRESTO 1000/P1000XL
